DC-2142FW
Supported Mobile Systems: iPhone OS, Sybian, Android
Supported Operating Systems: Windows 98, Windows XP, Windows
Connectivity: Wired IP Network
Image Sensor: 1/3” Progressive Scan CMOS
Min. Illumination: 0.07 lux @ (F1.2, AGC ON), 0 lux with IR
Shutter Time: 1/25 sec to 1/100,000 sec
Lens: 2.8mm@ F2.0, angle of view: 83°
IR cut filter with auto switch
Digital Noise Reduction: 3D DNR
Wide Dynamic Range: 120 dB
Video Compression: H.264 / MJPEG
Bit Rate: 32 Kbps ~ 16 Mbps
Dual Stream: Yes
Max. Image Resolution: 2688×1520
Image Settings: Rotate mode, Saturation, brightness, contrast adjustable by client software or web browser
BLC: Yes, zone configurable
ROI: Yes, up to 4 configurable areas
Alarm Trigger: Motion detection, Tampering alarm, Dynamic analysis
System Compatibility: ONVIF, PSIA, CGI, ISAPI
Operating Conditions: -30 °C ~ 60 °C (-22 °F ~ 140 °F)
Power Supply: DC12V ± 10% and PoE (802.3af)
