ASA5505-SEC-BUN-K9
ASA5505-SEC-BUN-K9 Specification | |
Product Number | ASA5505-SEC-BUN-K9 |
Product Description | Cisco ASA 5505 Unlimited-User Security Plus Bundle includes 8-port Fast Ethernet switch, 25 IPsec VPN peers, 2 SSL VPN peers, DMZ, stateless Active/Standby high availability, 3DES/AES license |
Users/Nodes | Unlimited |
Firewall Throughput | Up to 150 Mbps |
Maximum Firewall and IPS Throughput | ● Up to 150 Mbps with AIP-SSC-5 |
3DES/AES VPN Throughput | Up to 100 Mbps |
IPsec VPN Peers | 10; 25 |
SSL VPN Peers Included/ Maximum) | 2/25 |
Concurrent Connections | 10,000; 25,000 |
New Connections/ Second | 4000 |
Integrated Network Ports | 8-port Fast Ethernet switch (including 2 PoE ports) |
Virtual Interfaces (VLANs) | 3 (no trunking support)/20 (with trunking support) |
Security Contexts (Included/ Maximum) | 0/0 |
High Availability | Not supported; stateless Active/Standby and redundant ISP support |
Expansion Slot | 1, SSC |
User-Accessible Flash Slot | 0 |
USB 2.0 Ports | 3 (1 on front, 2 on rear) |
Serial Ports | 1 RJ-45 console |
Rack-Mountable | Yes, with rack-mount kit (available in the future) |
Wall-Mountable
| Yes, with wall-mount kit (available in the future) |
Security Lock Slot (for Physical Security) | Yes |
Memory | 256 MB |
Minimum System Flash | 64 MB |
System Bus | Multibus architecture |
Form Factor | Desktop |
Dimensions (H x W x D) | 1.75 x 7.89 x 6.87 in. (4.45 x 20.04 x 17.45 cm) |
Weight (with Power Supply) | 4.0 lb (1.8 kg) |
Safety | UL 60950, CSA C22.2 No. 60950, EN 60950 IEC 60950, AS/NZS60950 |
Electromagnetic Compatibility (EMC) | CE marking, FCC Part 15 Class B, AS/NZS CISPR22 Class B, VCCI Class B, EN55022 Class B, CISPR22 Class B, EN61000-3-2, EN61000-3-3 |
Industry Certifications | FIPS 140-2 Level 2. In process: Common Criteria EAL4+ US DoD Application-Level Firewall for Medium-Robustness Environments, and Common Criteria EAL4 for IPsec/SSL VPN |
