JL262A
JL262A Overview
Aruba 2930F Switch Series is designed for customer creating digital workplaces optimized for mobile users with an integrated wired and wireless approach. These basic Layer 3 access switches are easy to deploy and manage with advanced security and network management tools like Aruba ClearPass Policy Manager and Aruba AirWave and are ideal for enterprise edge, SMB and branch offices. A powerful Aruba ProVision ASIC delivers performance and value supporting the latest SDN applications with future proof programmability. The 2930F supports 10GbE uplinks, PoE+, robust QoS, RIP routing, Access OSPF, ACLs, Tunneled Node and IPv6. This JL262A has 48 x 10/100/1000 PoE+ ports and 4 x Gigabit SFP transceiver slots for uplink connectivity. PoE+ is supported with a power budget of 370 Watts.
Quick Spec
Table 1 shows the quick spec.
Product Code | JL262A |
Type | Aruba 2930F 48G PoE+ 4SFP Switch |
I/O ports and slots | 48 RJ-45 autosensing 10/100/1000 PoE+ ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T, IEEE 802.3at PoE+) Duplex: 10BASE-T/100BASETX: half or full 1000BASE-T: full only |
Additional ports and slots | 1 dual-personality (RJ-45 or USB micro-B) serial console port |
Throughput | up to 77.4 Mp/s |
Switching capacity | 104 Gb/s |
PoE Available Power | 370 W |
Dimensions | 4.39 x 44.25 x 30.42 cm ( 1.73 x 17.42 x 11.98 in) 1U height |
JL262A Specifications | |
| Specification | Details |
| Product Model | JL262A |
| Switch Series | Aruba 2930F |
| Ethernet Ports | 48 x Gigabit PoE+ RJ-45 |
| SFP Ports | 4 x 1G/10G SFP+ uplinks |
| Power consumption | 459 W (maximum) |
| Heat dissipation | 293 BTU/hr (309.1 kJ/hr) |
| Input voltage | 100 - 127 / 200 - 240 VAC, rated |
| Switching Capacity | 104 Gbps |
| PoE capability | 370 W PoE+ |
| Throughput | up to 77.4 Mpps |
| Power Input | Internal power supply (100-240V) with dual redundant power supplies option |
| Dimensions | 1.73 x 17.42 x 11.98 in |
| Operating Temperature | 0°C to 55°C |
| Operating Humidity | 15% to 95%, non-condensing |
