LGS105

Power-Saving Features

The auto power-down feature disables unused ports, smart power is ideal for short cable runs.

• Wired connection speed up to 1000 Mbps
• 5 Gigabit Ethernet auto-sensing ports
• Easy plug & play connection
• QoS
• Meets EEE (Energy Efficient Ethernet) 802.3az standard
• Power Consumption

  • 0.42W/2.01W

  LEDs

  • Link and activity indicators

  Dimensions (LxWxH)

  • 120 x 88 x 26 mm

  Weight

  • 0.252 kg

  Minimum System Requirements

  • Connected devices need Ethernet connectivity and Ethernet cables.

  Operating Humidity

  • 10–90% (non-condensing)

  Operating Temperature

  • 0–50°C

  Ports

  • 5 Gigabit Ethernet (10/100/1000) Ports

  Mounting

  • Wall

  Power Input

  • 12V 0.5A

  Storage Temperature

  • -40–70°C

  Warranty and Support

  • 5 Year Warranty

  MAC Address Table Size

  • 2,000 entries

  Performance

  • 0.01488Mpps for 10M port
  • 0.1488Mpps for 100M port
  • 1.488Mpps for 1000M port
  • Full line rate and forwarding rate of 64B frame at:

  Power

  • 110-240V AC, 50/60Hz, 5V DC, 1.0A

  Regulatory Compliance

  • FCC Class B, CE

  Fans

  • None

  Power Consumption

  • 0.73W / 2.22W

  Storage Humidity

  • 10–90% (non-condensing)

  Power Saving

  • Cable connected detection, sleep mode

  Network Standards

  • IEEE 802.3
  • IEEE 802.3ab
  • IEEE 802.3az
  • IEEE 802.3u
  • IEEE 802.3x

  Bandwidth

  • 10 Gbps (non-blocking)
