SM-X-ES3-24-P
Non-returnable
SAR5,320.00
Tags:
The Cisco Enhanced EtherSwitch Service Module runs independently of host router resource, it has their own processors, switching engines, flash memory and own upgradable IOS to ensure maximum concurrent switching and routing performance.
Choose Quantity
Product Details
The integration of Cisco Enhanced EtherSwitch Service Modules with existing router simplifies network management and troubleshooting, enhances scalability, offers investment protection and minimizes downtime that affects business operations.The Cisco Enhanced EtherSwitch Service Module runs independently of host router resource, it has their own processors, switching engines, flash memory and own upgradable IOS to ensure maximum concurrent switching and routing performance.
SM-ES3-24-P Specification
| Model info | SM-ES3-24-P | |
| Product Type | Cisco Enhanced EtherSwitch Service Module | |
| Port Density | 23 * 10/100 FE ports and 1 10/100/1000 GE port | |
| Power over Ethernet (PoE) | up to 20W per port | |
| Routing Protocol | RIP-1, RIP-2, HSRP, static IP routing, RIPng | |
| Remote Management Protocol | SNMP 1, SNMP 2,Telnet, SNMP 3, SNMP 2c, TFTP, SSH, CLI | |
| Authentication Method | Kerberos, Secure Shell (SSH), RADIUS, TACACS+ | |
| Supported router | 2911 / 2921 / 2951 / 3925 / 3945 | |
| Service Module Width | single slot | |
| Power Redundancy | RPS 2300 | |
| IP base feature | • QoS • ACLs • Static Routing • RIP v1,v2 • HSRP | |
| IP service feature | • IP unicast and IP Multicast routing • EIGRP • OSPF • BGP • PIM • IPv6 routing | • OSPFv3 • EIGRPv6 • IP SLA • VRF-lite |
| Security Features | • Dynamic ARP Inspection (DAI) • DHCP Snooping • IP Source Guard • Private VLANs • Unicast Reverse Path Forwarding (RPF) • IEEE 802.1x • Multidomain Authentication • MAC Authentication Bypass • Advanced ACLs • Administrative Traffic Protection • Switched Port Analyzer (SPAN) | • Centralized Authentication • MAC Address Authentication • Port Security • Console Security • Bridge Protocol Data Unit (BPDU) Guard • Spanning-Tree Root Guard (STRG) • Dynamic VLAN Assignment • IGMP Filtering |
